Measuring & Marking

Print-ready parametric measuring & marking. Support-free, oriented STL. Commercial license with StreamSolid Pro.

6 models

Pipe Hole Spacer V1

A sleeve that fits over a pipe on its outside diameter and locates two drill holes a set distance apart. Named sizes are IPS and metric pipe OD, not inner diameter. The CAD already includes 0.2 mm clearance on the bore and on each hole.

Angle Gauge V1

A flat disc with a sector cut to the angle you choose, engraved with that angle so you can tell one from another on the bench. Lay it on stock to mark or check an angle, set a bevel or miter against its edge, or use it to step off equal divisions around a circle.

Board Center Jig V1

A U-shaped jig that clips onto trim, a 2x4, a 2x6, or other lumber and locates a drill hole on center. Stock size is the actual face the jig hugs (3-1/2 in for a 2x4). Hole diameter is the drill. The CAD already includes 0.2 mm clearance on the opening and the hole.

Two-Hole Board Jig V1

A U-shaped jig that clips onto trim, a 2x4, a 2x6, or other lumber and locates two drill holes on center. Stock size is the actual face the jig hugs (3-1/2 in for a 2x4). Hole diameter is the drill. The CAD already includes 0.2 mm clearance on the opening and the holes.

Protractor Angle V1

Marks and checks precise angles for woodworking, metalworking, and layout work.

Center Finder Template V1

Marks the exact center on square or round stock for drilling and lathe mounting.
